Bosch 630cc Injectors

Bosch 630cc Injectors – High Performance Injectors

Bosch 630cc Injectors provide peak performance. This is a high performance, high volume racing fuel injector.

Mounted OEM on the following car models
Porsche 997 3,6 GT2 530HP 07-12
Porsche 997 3,6 GT2 RS 620HP 10-12
Porsche 3,6 Turbo 480HP 06-09

Name: Bosch 630cc
Part number: 0280158123 / 0280 158 123 / Bosch -123
OEM number:
997 605 132 00
997 605 132 01
997 605 132 02
Package: 1x
Connector: Bosch JPT EV1 Minitimer Jetronic
Length: 48,65mm – EV 14S (Standard) Use bottom adapter to get 60,65mm EV 14L (Long)
Injector tip: xT 24mm
O-ring top: 14mm Viton
O-ring bottom: 14mm Viton
Body diameter: 16mm
Impedance: 12 ohm
Spray pattern: 30 degrees 2 jets
Spray angle: Neutral (0 degrees)
Flow @ 3bar: 429g / 627cc/ 627cm3
Fuel: E85 / M100 compatible and can handle other standard fuels due to the stainless internal parts. ATTENTION! If the injector is to be run on methanol, it must be run through with regular fuel after use. These injectors must not be in contact with methanol over more extended periods.

Max flow measured static in test environment
29 PSI (2 bar) 492cc / min = 47 lb / h
43,5 PSI (3 bar) 612cc / min = 58 lb / h
58 PSI (4 bar) 708cc / min = 67 lb / h
78,5 PSI (5 bar) 738cc / min = 70 lb / h
88 PSI (6 bar) 870cc / min = 83 Ib / h
101,5PSI (7bar) 942cc / min = 90 lb / h

Please note that test environment versus practical use can vary widely depending on peripheral equipment and other technical factors. However, this is excellent information on what to expect from the injectors and essential information when choosing other components in the fuel system, such as fuel pump, fuel pressure regulator, and fuel filter.

Engine power Turbo
Petrol 10% margin
1cyl – 83hp (83×1)
4cyl – 332hp (83×4)
5cyl – 415hp (83×5)
6cyl – 498hp (83×6)
8cyl – 664hp (83×8)

Ethanol 10% margin
1cyl – 72hp (72×1)
4cyl – 288hp (72×4)
5cyl – 360hp (72×5)
6cyl – 432hp (72×6)
8cyl – 576hp (72×8)

Engine power N/A
Petrol 10% margin
1cyl – 108hp (108×1)
4cyl – 432hp (108×4)
5cyl – 540hp (108×5)
6cyl – 648hp (108×6)
8cyl – 864hp (108×8)

Ethanol 10% margin
1cyl – 90hp (90×1)
4cyl – 360hp (90×4)
5cyl – 450hp (90×5)
6cyl – 540hp (90×6)
8cyl – 720hp (90×8)
